The Bently Nevada 330907-05-30-05-02-00 3300 NSv Reverse Mount Probe is a high-precision, non-contact eddy-current displacement sensor engineered for demanding industrial condition monitoring and machinery protection applications. Manufactured by Baker Hughes (formerly Bently Nevada), a globally recognized leader in asset reliability and predictive maintenance technologies, this probe forms an integral component of the industry-standard 3300 NSv (Next-Generation System v) monitoring platform. Designed specifically for reverse-mount configurations—where the probe body is installed behind the target surface and the sensing face extends through a threaded bore—the 330907-05-30-05-02-00 enables accurate shaft vibration, axial position, differential expansion, and gap measurement in space-constrained or thermally sensitive environments. Its robust construction adheres to stringent API 670 (4th Edition) and ISO 10816 standards for machinery protection systems, ensuring compliance with critical rotating equipment specifications across oil & gas, power generation, petrochemical, and marine propulsion sectors. The probe operates on the principle of electromagnetic induction, generating a high-frequency magnetic field that interacts with conductive targets (typically 4140 steel, Inconel, or stainless steel) to produce a linear, temperature-compensated output proportional to target displacement. Each unit undergoes rigorous factory calibration using traceable NIST-certified reference standards and is supplied with a unique calibration certificate documenting sensitivity (mV/mil), linearity error (<±0.5% full scale), and thermal drift characteristics (≤0.02%/°C). As a new, factory-fresh unit, the 330907-05-30-05-02-00 carries a comprehensive 24-month limited warranty covering material defects and workmanship, reinforcing Baker Hughes’ commitment to long-term operational integrity and lifecycle support.

Detailed Specifications

Key Features

• True Reverse-Mount Design: Engineered with a precisely offset sensing face located 5 mm beyond the mounting surface—enabling installation in recessed housings, behind bearing caps, or within confined casings without compromising measurement accuracy or mechanical clearance.
• High-Fidelity Signal Integrity: Utilizes proprietary Bently Nevada NSv-series coil winding and ceramic substrate technology to minimize phase shift, harmonic distortion, and electromagnetic interference (EMI), delivering exceptional signal-to-noise ratio (>80 dB) even in electrically noisy turbine or compressor environments.
• Traceable NIST-Calibrated Performance: Supplied with individual calibration certificate referencing National Institute of Standards and Technology (NIST)-traceable standards, including full-range linearity plots, temperature compensation coefficients, and dynamic frequency response data (DC to 10 kHz).
• Corrosion-Resistant Construction: Housing fabricated from 316 stainless steel with PTFE-coated cable jacket and hermetically sealed ceramic insulator—certified for continuous operation in aggressive chemical, saline, and high-humidity conditions per ASTM B117 salt-spray testing.
• Plug-and-Play System Integration: Fully compatible with Bently Nevada 3300 NSv monitors, 3500/42M machinery protection systems, and legacy 3300 XL platforms—requiring no field recalibration when paired with matching extension cables and proximitor modules.
• Optimized Thermal Management: Integrated thermal compensation circuitry and low-thermal-expansion coil assembly ensure stable zero-point and sensitivity across extreme ambient gradients, critical for steam turbine differential expansion monitoring.
• Global Regulatory Compliance: Certified to ATEX II 2G Ex ia IIC T6 Ga, IECEx ia IIC T6 Ga, and UL/cUL Class I, Division 1, Groups A, B, C, D—enabling safe deployment in hazardous classified locations worldwide.

Applications

• Steam and Gas Turbines: Axial position monitoring of thrust collars, differential expansion between casing and rotor, and shaft vibration measurement at journal bearings—particularly where conventional front-mount probes are obstructed by bearing housing geometry.
• Centrifugal Compressors: Monitoring of impeller tip clearance, seal ring movement, and radial vibration in integrally geared or overhung configurations requiring rear-accessible probe placement.
• Large Electric Motors and Generators: Detection of rotor eccentricity, stator core movement, and frame vibration in encapsulated or double-cased units where external mounting is impractical.
• Petrochemical Pump Trains: Measurement of coupling end-shake, balance drum position, and sleeve bearing wear in API 610-compliant overhung and between-bearing pumps exposed to hydrocarbon vapors and process fluid ingress.
• Marine Propulsion Systems: Condition monitoring of reduction gear input/output shafts, stern tube bearing alignment, and propeller shaft runout in space-limited engine rooms subject to saltwater corrosion and wide thermal cycling.
• Nuclear Power Plant Auxiliary Systems: Safety-related vibration and position monitoring in reactor coolant pumps, feedwater heaters, and emergency diesel generators—meeting ASME OM Code, IEEE 344, and IEC 61508 SIL-2 requirements.
• Research & Development Test Benches: High-resolution dynamic testing of rotating components under controlled load, speed, and thermal conditions—leveraging the probe’s sub-micron resolution and broadband frequency response.
