Description

Configured for high-speed optical signal transmission in PLC-5 backplanes, the Allen Bradley 80190-100-01-R (80190-100 Fiber Optic Board) provides direct physical/electrical execution.

Hardware Specifications

Backplane Bus Communication Velocity & Network Integrity

The Allen Bradley 80190-100-01-R fiber optic board manages high-speed signal translation directly across the chassis backplane. Optimized backplane bus communication velocity guarantees deterministic data delivery and minimal latency between processing units and remote optical drops. Dual-channel optical transceivers provide galvanic immunity against extreme electromagnetic noise and ground potential differentials across distributed control topologies. Strict firmware flash compatibility ensures synchronized communication handling with PLC-5 processors, while high I/O density scaling preserves backplane bandwidth during continuous industrial operation.

Frequently Asked Questions

Q: How does the fiber optic interface board prevent signal degradation in high-EMI industrial enclosures?

A: The board converts electrical backplane signals into optical pulses for transmission over fiber optic cables, offering complete immunity to electromagnetic interference and high-voltage surges.

Q: Are there specific installation precautions regarding fiber optic bend radii?

A: Yes, optical cables connected to the board must adhere to minimum bend radius specifications (typically 30 mm) to prevent micro-bending signal attenuation and physical fiber breakage.

Field Installation Guidelines

• ESD Protection and Chassis Insertion: Ensure power to the PLC-5 chassis is fully isolated before inserting or removing the printed circuit board assembly. Wear a grounded wrist strap to prevent electrostatic discharge damage to sensitive optoelectronic components.
• Optical Cable Connection Standards: Clean fiber optic connectors with lint-free optical wipes and isopropyl alcohol prior to mating. Ensure positive mechanical latching without exceeding maximum cable tension limits.
• Grounding and Shielding Protocols: Verify chassis ground continuity from the rack assembly to the main earth ground bar. Maintain separation between fiber optic cables and high-voltage power wiring inside wireways to prevent physical abrasion.
