Description

Product Overview

The Yokogawa ATD5A-00 S1 serves as a high-density interface adapter specifically engineered for signal conversion and distribution within distributed control systems. This module facilitates the connection of field instrumentation to system I/O via KS-type cabling, thereby streamlining complex wiring architectures. By utilizing this interface, engineers effectively manage 32-point signal streams, ensuring high-fidelity data transmission between the process field and the centralized controller.

Technical Characteristics

• Configuration: Designed for 32-point signal handling, which optimizes cabinet space and reduces overall wiring complexity
• Connectivity: Features standardized KS cable interfaces that provide robust mechanical and electrical connections for industrial automation networks
• Compatibility: Integrates directly with Yokogawa control infrastructure, maintaining system-wide signal integrity and communication standards
• Reliability: Built to endure the demanding conditions of industrial control rooms while supporting high-speed, continuous data throughput
• Installation: Compact physical footprint allows for efficient mounting within standard automation cabinets

Technical Specifications

• Manufacturer: Yokogawa
• Model Number: ATD5A-00 S1
• Module Type: 32-Point KS Cable Interface Adapter
• System Integration: DCS Compatibility
• Dimensions: 3.2 cm x 3.5 cm x 11.3 cm
• Weight: 0.06 kg
• Harmonized System (HS) Code: 8537101190
• Product Status: Active

Operational Application
