Description

The Schneider Electric MC-4/11/10/400 is a high-performance servo drive controller within the PacDrive M series. This unit delivers precise motion control for complex packaging machinery and automated production lines. It integrates high-speed power electronics with sophisticated communication protocols to manage up to 40 motion axes.

Technical Functionality and System Integration

This controller utilizes the SERCOS interface to ensure real-time synchronization between the drive and the central PLC. The hardware version E0R603 provides a stable platform for demanding industrial environments. It supports multiple fieldbus standards including PROFIBUS-DP and CANopen for flexible system architecture.

The SW:V00.12.XX firmware optimizes motor control algorithms to improve machine cycle times. Engineers use the EPAS-4 programming environment to configure the device according to IEC 61131-3 standards. This software compatibility allows for seamless logic and motion programming within a single tool.

Operational Characteristics

• Manufacturer: Schneider Electric (formerly Elau)
• Product Series: PacDrive M
• Control Bus: SERCOS real-time interface
• Input Voltage: 400V AC
• Programming: IEC 61131-3 compliant
• Weight: 3.54 kg
• Dimensions: 6.8 x 24.5 x 31 cm

Industrial Applications

This drive serves primarily in high-speed packaging applications. It excels in labeling, wrapping, and filling processes where precision is critical. The module supports modern OPC data exchange to bridge the gap between field devices and enterprise systems.
