Description

The GE IC695PNC001, also cataloged as the IC695PNC001 PROFINET Controller Module, operates as a dedicated hardware component for deterministic network packet routing and I/O device management within PACSystems RX3i control platforms.

Hardware Specifications

Backplane Bus Communication Velocity Licences and Deterministic Networking

The module interfaces directly with controller processor nodes via high-speed internal backplane buses. Firmware flash compatibility governs the interaction between the network controller firmware and core execution loops, ensuring deterministic packet transfer and zero frame dropping during real-time data exchange. Profinet and EtherNet/IP protocol layers process communication packets synchronously, updating network nodes without command latency across ring, star, and daisy-chain topologies.

Frequently Asked Questions

Q: Can the IC695PNC001 module be extracted while the RX3i backplane remains powered?

A: Yes. The hardware supports removal and insertion under power (RIUP) without disrupting ongoing rack control operations or neighbouring module functions.

Q: How does the module handle power distribution when SFP devices are installed?

A: The internal power regulation draws 0.5 A without SFP devices and scales up to 1.2 A when two SFP optical modules are populated, up to a maximum draw of 1.5 A at 5.5 VDC.

Field Installation Guidelines

Ensure the designated backplane slot is aligned with the module guide rails prior to insertion. Push the unit straight into the chassis until the rear connector pins engage fully with the backplane bus, then secure the top and bottom retaining screws to maintain structural grounding and mechanical stability in high-vibration industrial enclosures.
