Description

Configured for proximity probe signal transmission in machinery protection systems, the Bently Nevada 176449-09 (176449 Interconnect Cable) provides direct physical/electrical execution.

Hardware Specifications

Machinery Monitoring and TSI Characteristics

The interconnect link utilizes specialized shielding matrices to guarantee cross-talk suppression between parallel proximity sensor runs during high-velocity rotor dynamics analysis. The structural geometry preserves strict eddy-current probe scaling configurations, maintaining voltage sensitivity linearity even under extreme thermal gradients. This structural integrity prevents deviations during critical gap voltage validation sequences targeting the standard -10 VDC operational benchmark.

Frequently Asked Questions

Q: Can the 176449-09 cable be cut to a custom length in the field?

A: No, modifying the physical length alters the total nominal capacitance and loop impedance, which invalidates eddy-current probe scaling and shifts the calibrated gap voltage baseline.

Q: What prevents the connector junctions from loosening due to machine vibration?

A: The hardware incorporates a mechanical click-lock coaxial connector design that establishes a positive engagement, preventing vibration-induced drift or intermittent electrical contact.

Field Installation Guidelines

Ensure all coaxial connector threads are clear of moisture, oil, and particulate contaminants before mating. Apply self-fusing silicone tape over the connector junctions to establish an environmental seal against fluid ingress. Route the cable through dedicated, grounded metal conduit, maintaining a minimum bend radius of 25.4 mm to avoid internal dialectic deformation. Secure the outer shield braid firmly to the proximal transmitter housing terminal to block electromagnetic interference loop paths.
