Bently Nevada 102242-00-05-50 Vibration Transmitter
Bently Nevada 102242-00-05-50 industrial vibration transmitter module. Brand New, Original Stock, Global Shipping.
Description
Configured for high-performance vibration measurement in machinery protection and control systems, the Bently Nevada 102242-00-05-50 (102242 Vibration Transmitter) provides direct physical/electrical execution. The hardware employs an integrated vibration sensor to continuously track dynamic casing displacement or velocity changes, converting raw mechanical inputs into a stabilized analog current loop for direct transmission to industrial PLC, DCS, and SCADA systems.
Suffix Breakdown & Model Matrix
| Parameter | Specification |
|---|---|
| 102242 | Core base hardware platform indicating an integrated industrial vibration transmitter assembly |
| -00 | Primary mechanical option defining standard internal structural components and baseline housing profiles |
| -05 | Calibration option mapping the specific full-scale range allocation proportional to targeted mechanical loads |
| -50 | Standard hardware revision suffix specifying certified production baselines and default environmental sealing configurations |
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 102242-00-05-50 |
| Brand | Bently Nevada |
| Origin | USA |
| Weight | 500 g |
| Dimensions | Standard cylindrical/block transmitter housing footprint |
| Operating Temp | -40 to +85 deg C |
| Power Consumption | Determined by current loop limits (30 VDC maximum load allocation) |
| Sensor Type | Integrated vibration sensor |
| Output Signal | 4-20 mA proportional to vibration level |
| Frequency Response | Optimized for industrial machinery vibration detection |
| Power Supply Requirement | 12-30 V DC |
| Enclosure Rating | IP65 or higher (depending on installation configuration) |
| Mounting | Directly onto machinery or within monitoring panels |
Machinery Monitoring & TSI Characteristics
The module processes mechanical oscillations to evaluate rotor dynamics and detect structural casing stresses before breakdown occurs. To establish continuous path verification, the physical loop maintains direct tracking limits against calibrated eddy-current probe scaling baselines. The electronic instrumentation implements real-time noise suppression and filtering arrays, executing gap voltage validation (-10 VDC targets) internally across the diagnostic circuits to isolate structural hardware anomalies and maintain cross-talk suppression under intense electromagnetic conditions.
Frequently Asked Questions
Q: How does the 102242-00-05-50 respond to an out-of-range physical vibration spike?
A: The transmitter drives its internal output signal up to the physical loop saturation threshold based on the configured 4-20 mA span. External host PLC or DCS networks process this peak analog limit as a severe machinery fault condition.
Q: Can the transmitter operate continuously while the loop voltage drops to exactly 12 V DC?
A: Yes. The hardware is specified to function within a 12-30 V DC power supply envelope. Consequently, as long as the terminal voltage does not fall below 12 V DC under full load current, measurement accuracy is maintained.
Field Installation Guidelines
- Mount the unit directly onto the targeted rotating equipment using rigid mechanical thread adapters to prevent localized resonance from altering data tracking.
- Route the two-wire 4-20 mA loop cable through grounded, rigid steel conduits to prevent high-frequency noise interference from adjacent power distributions.
- Terminate all external cable shields cleanly at a single-point instrumentation ground node located within the control panel interface.
