Description

Product Overview

The Allen Bradley 2711P-RP1X is a core processing units module designed for the PanelView Plus and PanelView Plus CE operator interface terminal families (covering 700, 1000, 1250, and 1500 graphic displays). Serving as the main computing engine, this logic module mounts directly onto the rear of a compatible display module to form a complete human-machine interface (HMI). By managing the operating system, internal memory allocation, and physical communication ports, the component ensures high-speed graphic rendering and seamless execution of industrial machine visualization software.

Core Technical Specifications

• Manufacturer: Allen Bradley / Rockwell Automation
• Model Number: 2711P-RP1X
• Component Type: HMI Replacement Logic Module
• Product Family Alignment: PanelView Plus / PanelView Plus CE 700-1500
• Internal Storage Configuration: 128 MB Flash Memory / 128 MB RAM
• Input Voltage Requirement: 24V DC
• Net Hardware Weight: 0.66 kg
• Physical Proportions: 20.8 x 14.0 x 4.5 cm
• Lifecycle Status: Active Production Line
• Harmonized Tariff Classification (HS Code): 8537101190

Industrial Applications and System Deployment

This processing module is frequently deployed within large-scale industrial sectors, including automotive assembly plants, automated food packaging lines, and water treatment operations. Technicians utilize the module to run complex supervisory control interface profiles generated via FactoryTalk View Machine Edition (ME) software. Consequently, plant operators can monitor live tank levels, control motor speeds, clear active system faults, and manage automated machine timing scripts directly from the factory floor.

Operational Characteristics and Functional Advantages

• Integrated Communications Architecture: The hardware layout includes onboard communication channels, enabling direct, high-speed data exchanges with ControlLogix and CompactLogix programmable automation controllers.
• Windows CE Platform Support: The open architecture provides built-in compatibility with standard utility tools, terminal server-client applications, and web browser utilities for remote diagnostic accessibility.
• Dynamic Software Execution: Equipped with expanded memory registers, the board handles heavy application data loads, historical trends, high-resolution alarm logging, and multi-language script switching efficiently.
• Modular Assembly Concept: The design permits quick mechanical separation from the display panel, meaning maintenance crews can replace computational logic cards without replacing the front display bezel assembly.
