Description

The Allen-Bradley 1756-CNBR provides deterministic, high-speed communication within the ControlLogix hardware ecosystem. This bridge module links the controller backplane to the ControlNet network efficiently. It serves as an essential interface for both local and distributed I/O configurations. Because it supports redundant media, the module ensures maximum system uptime in critical environments. It handles scheduled data for real-time control and unscheduled data for messaging tasks.

Core Technical Specifications

Network Redundancy and Reliability

The 1756-CNBR features dual BNC connectors to support redundant network cabling. This architecture protects the control system from single points of failure. If one cable segment fails, the module maintains communication through the secondary path. Consequently, this prevents costly process interruptions in continuous manufacturing sectors. The hardware uses quad-shield RG-6 coaxial cables to ensure high signal integrity. It provides a significant upgrade over standard single-port bridge modules for high-availability systems.

System Integration and Configuration

This module slots directly into any 1756 ControlLogix chassis. It works seamlessly with Logix5550 and newer controllers for distributed control. System designers can use the 1756-CNBR as a remote I/O adapter or a local bridge. The front-facing Network Access Port allows for convenient local programming and diagnostics. Furthermore, the module supports up to 20 unconnected message buffers for flexible data exchange. It remains compatible with standard 1756-A4 through 1756-A17 racks and various power supplies.

Advanced Diagnostics and Installation

Multiple status indicators on the module faceplate provide real-time hardware and network diagnostics. These visual tools help technicians identify link status and module health quickly. During installation, users must ensure correct tap drop cable orientation for stable connectivity. The module operates reliably within standard industrial temperature ranges for automation cabinets. Its deterministic nature makes it ideal for synchronized motion and high-speed process applications.
