Product Description

The Allen-Bradley 1503VC-BMC5 serves as a high-performance IntelliVAC control interface specifically engineered to manage and safeguard Bulletin 1502 vacuum contactors. This module facilitates precise regulation for both 400 Amp and 800 Amp units, ensuring that motor control systems maintain peak operational integrity. By integrating this module, operators can effectively manage both mechanically latched and electrically held contactor configurations within a unified system architecture.

Reliability remains a core feature of the 1503VC-BMC5, as it provides a comprehensive suite of protective functions. The module actively monitors for electrical irregularities, offering robust defense against phase loss, sustained overloads, and hazardous short-circuit conditions. These diagnostic capabilities significantly reduce the risk of motor failure and minimize unscheduled downtime in demanding industrial environments.

Furthermore, the hardware supports a wide range of global power standards, accepting input voltages from 110V to 240V AC at frequencies of either 50Hz or 60Hz. The compact physical footprint allows for straightforward integration into existing PLC-controlled cabinets. Through the use of Ethernet-based communication services, the module enhances system visibility, allowing for streamlined data exchange and more efficient motor management strategies.

Technical Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model Identification: 1503VC-BMC5
• Equipment Class: IntelliVAC Control Module
• Compatible Hardware: Bulletin 1502 Vacuum Contactors (400A / 800A)
• Input Voltage Range: 110VAC to 240VAC
• Frequency Support: 50/60 Hz
• Protection Suites: Overload, Phase Loss, and Short Circuit
• Control Logic: Supports Electrically Held and Mechanically Latched
• Communication: Ethernet Router Service
• Physical Dimensions: 6 x 16.7 x 18.5 cm
• Net Weight: 1.2 kg
