Description

Configured for proximity displacement and vibration sensing in 3300 XL NSv Proximity Transducer System platforms, the Bently Nevada 330909-00-99-10-02-00 (330909 Proximity Probe) provides direct physical/electrical execution.

Suffix Breakdown & Model Matrix

• 00: Unthreaded Length Option (0 in unthreaded length)
• 99: Overall Case Length Option (9.9 in total case length)
• 10: Total Length Option (1.0 meter or 3.3 feet system length)
• 02: Connector and Cable-Type Option (Miniature coaxial ClickLoc connector, standard cable)
• 00: Agency Approval Option (No approvals required)

Hardware Specifications

Eddy-Current Transducer Calibration and Gap Voltage Validation

The proximity probe employs high-frequency eddy-current fields to monitor fast-acting rotor dynamics within narrow installation envelopes. Field engineers must execute precise gap voltage validation during positioning, adjusting the probe physical gap to establish a target baseline of -10 VDC at the Proximitor output terminal. Furthermore, the localized internal coil architecture optimizes cross-talk suppression. This targeted configuration mitigates side-view magnetic field distortion and prevents measurement anomalies when tracking targets smaller than 15 mm.

Frequently Asked Questions

Q: Why does this probe model feature an integrated armored cable sleeve option?

A: The stainless steel armor surrounding the internal FEP-insulated coaxial path resists mechanical abrasion, hot oil degradation, and physical pinching common inside fluid-filmed bearing housings.

Q: How do the standard ClickLoc coaxial connectors protect the raw signal integrity?

A: The ClickLoc configuration features a mechanical locking arrangement that resists severe industrial vibration. Consequently, the coupling prevents loose connection cycles and maintains consistent impedance profiles across the loop.

Field Installation Guidelines

Engineers must maintain explicit side-clearance zones when routing the armored coaxial path inside machine casings to eliminate interference from nearby structural counterbores. Secure the threaded probe body into the mounting bracket using a minimum of 5-扣 engagement or specified torque settings to prevent axial drift under thermal expansion. Run the low-voltage sensor lead wire in isolated, grounded conduit channels separated from high-current motor feeds, and terminate the outer common shield directly at the instrumentation panel ground.
