Description

Configured for shaft vibration and axial position measurement in restricted machinery housings, the Bently Nevada 330905-00-25-05-02-05 (330905 Proximity Probe) provides direct physical/electrical execution. This eddy-current sensor features a reverse-mount configuration that allows technicians to install or adjust the probe from the outside of the machine housing where physical space is constrained.

Hardware Specifications

Eddy-Current Probe Scaling and Rotor Dynamics Calibration

The Bently Nevada 330905-00-25-05-02-05 generates a high-frequency electromagnetic field that interacts directly with conductive metal targets. Consequently, changes in the gap distance modulate the eddy-current amplitude, which the connected 3300 NSv Proximitor sensor converts into a linear voltage. Because this probe utilizes a smaller 5 mm tip diameter, it maintains an accurate scale factor of 7.87 V/mm (200 mV/mil) even when targeting narrow shaft surfaces down to 9.5 mm (0.375 inches) in diameter. Furthermore, the specialized design provides robust cross-talk suppression when field technicians route adjacent probe cables inside compact bearing housings. Ultimately, this tight electrical calibration yields stable gap voltage validation, targeting a nominal -10 VDC center-point within the linear range.

Frequently Asked Questions

Q: How does the reverse-mount configuration affect the physical installation process?

A: Unlike standard forward-mount probes, the reverse-mount probe housing threads into the mounting bracket from the rear. This design permits external access and allows technicians to adjust the gap voltage without removing the machinery covers or bearing caps.

Q: What function does the coaxial armor option provide on this specific model?

A: The flexible stainless steel armor jacket prevents mechanical abrasion, cutting, and pinching of the internal coaxial cable. Concurrently, it shields the dielectric layer from harsh oil mist and chemical contaminants present inside the machine housing.

Field Installation Guidelines

• Verify Side Clearance: Maintain a minimum of 9.5 mm (0.375 inches) of clear space around the probe tip to prevent counterbore interference from altering the calibration.
• Observe Thread Torque Limits: Tighten the 3/8-24 UNF threaded probe body into the sleeve using a calibrated torque wrench. Do not exceed 11.3 N-m (100 in-lb) to avoid stripping or structural deformation.
• Isolate Armored Shields: Ensure that the outer coaxial armor does not touch internal machine surfaces or metal conduit walls. This precaution prevents external ground loops from degrading the proximity signal.
• Secure Miniature Connectors: Inspect and clean the miniature coaxial connections before assembly. Afterward, tighten the connectors finger-tight and apply self-fusing silicone tape to seal out moisture.
