Description

Brief Product Description

The GE Fanuc IC200MDD841 is a high-performance VersaMax expansion module that combines 20 discrete inputs and 12 discrete outputs with 80kHz high-speed counting capabilities. It provides advanced motion control features, including Pulse Width Modulation and pulse train outputs, in a compact industrial form factor.

Product Description

Integrated High-Speed Motion Control

The GE Fanuc IC200MDD841 serves as a specialized mixed I/O module within the VersaMax PLC family, engineered specifically for high-velocity pulse processing. It features four high-speed counter pairs capable of reaching frequencies up to 80kHz, making it an ideal choice for encoder interfacing and precision positioning tasks. By consolidating 20 discrete inputs and 12 discrete outputs into a single unit, the module maximizes rack efficiency while providing the rapid response times required for modern motion control applications.

Versatile Functional Configurations

System designers can adapt the IC200MDD841 module to various operational modes through flexible software configuration. Beyond standard high-speed counting, the unit supports Pulse Width Modulation (PWM), ramping pulse trains, and steady-state pulse train outputs. In its default state, the module allocates resources for four counter pairs and eight general-purpose outputs. This versatility allows the same hardware to manage diverse tasks, from simple flow meter monitoring to complex servo motor control. The module continuously monitors internal operation and can report diagnostics across a data range of up to 13 words to the main CPU.

Power Requirements and Visual Diagnostics

The VersaMax IC200MDD841 operates on a standard 24V DC external supply for its I/O circuits while drawing a lean 30mA from the 5V backplane power. Although the module does not include internal channel isolation or fuses, it prioritizes real-time status visibility through an integrated LED array. These indicators allow maintenance personnel to verify power health and I/O activity at a glance. Its small footprint ensures a seamless fit into space-constrained control cabinets, providing a robust and scalable solution for automated manufacturing and high-speed packaging lines.
