Description

The GE Fanuc IC698CPE010 serves as the primary processing engine for the PACSystems RX7i automation platform. This high-performance CPU utilizes an Intel Celeron 300 MHz microprocessor to manage large-scale industrial applications. It delivers exceptional computational speed with a Boolean execution rate of 0.33 ms per 1,000 contacts. Furthermore, the module features a rugged VME-based design for high-reliability environments. It excels in complex data processing and real-time control for demanding manufacturing sectors. This unit provides the necessary power for sophisticated logic and system-wide management.

Memory and Data Management

This CPU offers 10 MB of user RAM to handle extensive logic programs and data tables. It also includes 10 MB of non-volatile flash memory for secure permanent storage. Each individual program block can reach a maximum size of 128 KB. Additionally, the system supports comprehensive floating-point calculations for precision control loops. The battery-backed architecture ensures that critical process variables remain safe during power interruptions. Users can configure and program the entire system through Proficy Machine Edition software.

Communication and Connectivity

The IC698CPE010 features diverse connectivity options for seamless network integration. It includes three dedicated serial ports supporting RS-232 and RS-485 protocols. Moreover, dual 10/100 Mbps Ethernet ports facilitate high-speed data exchange across the enterprise. The module supports multiple protocols including EGD, SRTP, and MODBUS TCP/IP. It also utilizes Media Redundancy Protocol (MRP) to ensure continuous network availability. Auto-negotiation features allow the hardware to adapt to various network speeds automatically.

Industrial Reliability and Performance

Built on the proven RX7i VME64 backplane, this module provides superior data throughput and stability. It manages up to 32K discrete points and 32K analog words with ease. Integrated diagnostics help technicians identify hardware faults and communication errors rapidly. The front panel includes status LEDs for CPU health, battery condition, and port activity. This module operates effectively in temperature ranges from 0°C to 60°C. Its robust construction makes it ideal for power plants and heavy machinery control.

Technical Specifications

• Manufacturer: GE Fanuc / Emerson
• Model Number: IC698CPE010
• Processor: Intel Celeron 300 MHz
• User Memory: 10 MB Battery-Backed RAM
• Non-Volatile Storage: 10 MB Flash Memory
• Discrete I/O Capacity: 32,768 Inputs and Outputs
• Analog I/O Capacity: 32,768 Words
• Boolean Execution: 0.33 ms per 1,000 contacts
• Programming Support: Up to 512 Program Blocks
