The GE Fanuc IC697CHS750 is a professional-grade 5-slot rear mount chassis designed for the Series 90-70 PLC architecture. This foundational rack provides a secure housing and high-speed backplane for module-to-module communication and power distribution.

Product Description

Versatile System Foundation

The GE Fanuc IC697CHS750 serves as a robust housing solution for the Series 90-70 PLC line. By providing five dedicated slots for module installation, this rack allows engineers to configure compact yet powerful control systems. The chassis functions as a central communication hub, facilitating high-speed data exchange across the backplane to ensure peak system performance. Its rear-mount design specifically aids in space optimization within industrial control cabinets, making it a staple for factory automation and large-scale process control.

Power Management and Thermal Stability

Reliability remains a priority for the IC697CHS750 chassis, which supports power supply units positioned on the left side of the assembly. The rack handles a substantial current rating of 20 Amps at a standard 5V DC supply, providing ample energy for high-density I/O configurations. To maintain long-term component health, the chassis utilizes a passive convection cooling design. This architecture leverages natural airflow to dissipate heat generated by the modules. Consequently, operators should maintain clear clearance between the rack and surrounding equipment to maximize thermal efficiency and prevent overheating.

Installation and Wiring Efficiency

GE Fanuc designed the IC697CHS750 with maintenance and ease of installation in mind. The unit features a hinged access door that protects a removable terminal block, allowing for quick wiring changes without disturbing the entire module array. Furthermore, a specialized terminal restraining strap ensures that all cables remain securely fastened even in high-vibration environments. To enhance signal clarity and reduce electromagnetic interference, the rack includes dedicated grounding points. These features, combined with accessories like the J2 jumper kit, provide a comprehensive solution for engineers seeking a stable and scalable PLC platform.
