Description

Configured for secure machinery data acquisition in Bently Nevada monitoring networks, the Bently Nevada 2155/40 (2155/40 TDISecure Communication Processor) provides direct physical/electrical execution.

Hardware Specifications

Rotor Dynamics Data Processing and TSI Signal Management

The Bently Nevada 2155/40 TDISecure Communication Processor processes synchronized machinery protection data from vibration and Keyphasor measurement channels. It supports rotor dynamics analysis by maintaining high-speed signal acquisition without multiplexing delays.

The processor maintains eddy-current probe scaling compatibility for shaft vibration and position measurements. Furthermore, it supports gap voltage validation procedures using typical -10 VDC target references for proximity probe systems.

The hardware architecture reduces signal cross-talk through differential input design and controlled channel processing. Therefore, the module maintains measurement consistency when multiple dynamic channels operate simultaneously.

Frequently Asked Questions

Q: How does the module maintain channel isolation across multiple dynamic inputs?

A: The processor uses differential input topology across all 24 dynamic analog channels, preventing ground loops and suppressing cross-talk during high-frequency signal acquisition.

Q: What are the input requirements for eddy-current probe gap voltage validation?

A: The dynamic analog channels accept a voltage range from -25 V to +25 V, allowing direct verification of standard proximity probe bias outputs, such as nominal -10 VDC gap settings.

Q: Can the processor operate using dual redundant power inputs?

A: Power availability depends on ordering variant 2155/40-01 for 100-240 VAC supply lines or variant 2155/40-02 for 20-36 VDC direct-current field networks.

Field Installation Guidelines

• Ensure the housing enclosure is grounded to the primary cabinet Earth bus using a short, low-impedance conductor prior to applying system power.
• Route dynamic signal and Keyphasor input cables through dedicated, shielded conduits separate from AC mains power line paths.
• Maintain signal shield continuity up to the field terminal connections, isolating shield drains at one single grounding point to eliminate ground loops.
• Verify field wiring polarity and voltage ranges (-25 V to +25 V for dynamic inputs) before connecting field terminal blocks to prevent damage.
• Allow sufficient enclosure clearance surrounding the chassis to maintain natural convection airflow across the specified operating temperature range.
