Bently Nevada 134M2166-01 134M6794-01 Ranger Pro Wireless Sensor
Bently Nevada 134M2166-01 134M6794-01 Ranger Pro Wireless Sensor Assembly. Brand New Original Stock available for Global Shipping.
Description
The Bently Nevada 134M2166-01 134M6794-01, also cataloged as the 134M2166 Wireless Triaxial Sensor Assembly, operates as a dedicated hardware component for wireless vibration and surface temperature data acquisition within Ranger Pro condition monitoring networks.
Suffix Breakdown & Model Matrix
| Option Code | Description |
|---|---|
| 134M2166-01 | Primary Sensor Base Module with Triaxial Accelerometer & Temperature Element |
| 134M6794-01 | Associated Mounting Base / Sensor Hardware Sub-Assembly Option |
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 134M2166-01 134M6794-01 |
| Brand | Bently Nevada |
| Origin | USA |
| Weight | Standard Sensor Module Weight |
| Dimensions | Compact Stud-Mount Industrial Enclosure |
| Operating Temp | -40 deg C to +85 deg C |
| Power Consumption | Replaceable internal high-capacity lithium battery |
| Product Type | Wireless Triaxial Sensors |
| Measurement Type | Triaxial Acceleration / Velocity (X, Y, Z axes) and Surface Temperature |
| Wireless Protocol | ISA100.11a / WirelessHART |
| Mounting Base | Integrated Threaded Adapter Base (134M6794-01) |
| Ingress Protection | IP67 / Hazardous Area Certified |
Transducer Signal Conditioning & Rotor Dynamics
The 134M2166-01 134M6794-01 converts multi-axis dynamic vibration signals and casing temperature measurements into digitized data packets for industrial wireless routing. Internal signal conditioning paths scale acceleration and velocity inputs while maintaining active cross-talk suppression between orthogonal measurement channels. This multi-axis processing capability supports precise tracking of rotor dynamics, enabling early diagnostic detection of shaft misalignment, unbalance, mechanical looseness, and bearing degradation.
Frequently Asked Questions
Q: What role does the 134M6794-01 part play in the sensor assembly?
A: The 134M6794-01 serves as the designated mounting adapter base interface that secures the 134M2166-01 primary sensor module to the machine housing.
Q: How does the 134M2166-01 134M6794-01 maintain measurement channel accuracy across three axes?
A: Integrated signal processing circuits maintain cross-talk suppression between orthogonal channels, ensuring isolated dynamic signal acquisition for the X, Y, and Z axes.
Field Installation Guidelines
- Thread the 134M6794-01 mounting base directly onto a prepared threaded stud on the machine bearing housing, applying proper installation torque.
- Mount the 134M2166-01 primary sensor onto the 134M6794-01 base assembly, ensuring metal-to-metal contact to preserve high-frequency vibration transmission and thermal conductivity.
- Align the wireless antenna housing to maintain an unobstructed line-of-sight pathing to the nearest network gateway or router node.
- Check that all environmental seals are properly seated to preserve IP67 ingress protection prior to field commissioning.
Additional information
| Weight | 0.30 kg |
|---|---|
| Dimensions | 64 × 34 × 62 mm |
