Bently Nevada 135M1467-01 Ranger Pro Wireless Sensor
Bently Nevada 135M1467-01 Ranger Pro Wireless Sensor. Brand New Original Stock available for Global Shipping.
Description
The Bently Nevada 135M1467-01, also cataloged as the 135M1467 Wireless Triaxial Sensor, operates as a dedicated hardware component for wireless vibration and surface temperature data acquisition within Ranger Pro condition monitoring networks.
Suffix Breakdown & Model Matrix
| Option Code | Description |
|---|---|
| 135M1467 | Base Model Number for Ranger Pro Wireless Sensor Assembly |
| -01 | Specific Hardware Assembly / Frequency Response and Mount Variant |
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 135M1467-01 |
| Brand | Bently Nevada |
| Origin | USA |
| Weight | Standard Sensor Module Weight |
| Dimensions | Compact Stud-Mount Industrial Sensor Enclosure |
| Operating Temp | -40 deg C to +85 deg C |
| Power Consumption | Replaceable internal lithium battery power supply |
| Product Type | Wireless Triaxial Sensors |
| Measurement Type | Triaxial Acceleration / Velocity (X, Y, Z axes) and Surface Temperature |
| Wireless Protocol | ISA100 / WirelessHART |
| Mounting Format | Threaded Base Mounting Stud |
| Protection Rating | IP67 / Hazardous Location Certified |
Transducer Signal Conditioning & Rotor Dynamics
The 135M1467-01 conditions dynamic vibration signals across three orthogonal axes (X, Y, Z) and casing temperature measurements for wireless protocol serialization. Internal signal conditioning paths scale multi-axis acceleration and velocity values while executing active cross-talk suppression between measurement channels. This multi-axis acquisition architecture supports precise dynamic evaluation of rotor dynamics, tracking spectral shifts related to shaft unbalance, mechanical looseness, bearing degradation, and structural resonance.
Frequently Asked Questions
Q: How does the 135M1467-01 prevent signal interference between measurement axes?
A: The sensor integrates multi-channel conditioning circuits with active cross-talk suppression to isolate orthogonal X, Y, and Z axes prior to wireless packet transmission.
Q: How is operating power provided to the 135M1467-01 module?
A: The hardware operates on an internal, field-replaceable high-capacity lithium battery designed for low-power wireless industrial telemetry.
Field Installation Guidelines
- Thread the 135M1467-01 directly onto a prepared metal mounting stud on the machine bearing housing, torqueing to specification to ensure rigid contact.
- Ensure flat, clean contact between the metallic base and casing surface to achieve accurate temperature conduction.
- Align the sensor antenna area to maintain a clear line-of-sight path to the nearest wireless field gateway or repeater.
- Verify that housing seals and battery compartment caps are properly seated to preserve IP67 ingress protection in hazardous field locations.
Additional information
| Weight | 0.30 kg |
|---|---|
| Dimensions | 64 × 15 × 43 mm |
