The ABB AI810 3BSE008516R1 is a high-performance 8-channel analog input module engineered for the S800 I/O system. It provides precise 12-bit conversion for both voltage and current signals, facilitating seamless communication between field sensors and the Advant-800xA control environment.

Product Description

High-Precision Signal Acquisition

The ABB AI810 serves as a specialized 8-channel interface within the S800 I/O family, specifically designed to capture analog data with superior accuracy. Each of the eight unipolar channels operates independently, allowing engineers to configure inputs for standard voltage ranges (0–10V, 2–10V) or current loops (0–20mA, 4–20mA). By utilizing a 12-bit resolution architecture, the module ensures that process variables are converted into digital data with minimal loss, maintaining a full-scale error margin of only ±0.1%. This level of precision makes the module an ideal choice for industries where tight process control is a fundamental requirement.

Advanced Diagnostics and Safety Features

To ensure maximum system uptime, the 3BSE008516R1 module incorporates robust protection and diagnostic capabilities. It supports the HART communication protocol, which allows operators to retrieve secondary diagnostic information directly from smart field instruments. Furthermore, the hardware features built-in short-circuit protection and input shunt resistors that withstand overvoltages up to 30V. To maintain signal purity in high-interference environments, the module provides 2500V isolation, effectively shielding the controller logic from field-side electrical noise and surges.

Durable Industrial Integration

ABB manufactures the AI810 in Sweden to meet rigorous international standards for DCS and machine automation. The module’s IP20-rated housing is optimized for DIN rail mounting within control cabinets, functioning reliably in ambient temperatures ranging from -20°C to +60°C. Because it integrates natively with the Advant-800xA system, it streamlines the engineering process and reduces configuration time. Whether deployed in test measurement stations or large-scale process control facilities, this analog input module delivers the durability and data integrity required for modern industrial operations.
