Description

Technical Overview

The Bently Nevada 3500/40M Position Monitor is a high-precision, rack-mounted module engineered for continuous, real-time monitoring of shaft position, axial displacement, and differential expansion in critical rotating machinery. Designed for integration into the industry-standard 3500 Machinery Protection System (MPS), this monitor delivers exceptional signal integrity and diagnostic reliability across demanding industrial environments—including power generation, oil & gas, petrochemical, and large-scale manufacturing facilities. Its advanced digital signal processing architecture ensures immunity to electromagnetic interference (EMI), thermal drift, and vibration-induced noise—making it ideal for mission-critical applications where measurement accuracy directly impacts asset integrity and operational safety.

Operating with compatible proximity probe transducers (e.g., 3300 series), the 3500/40M supports dual-channel configuration for redundant or differential measurements, enabling precise detection of thrust position shifts, bearing wear, and rotor misalignment. The module features built-in self-diagnostics, configurable alarm thresholds (with both warning and danger setpoints), and seamless communication via Modbus RTU or Ethernet/IP for integration with DCS, SCADA, and predictive maintenance platforms. With UL, CSA, and ATEX certifications for hazardous locations (when used with approved barriers), the 3500/40M meets stringent global compliance requirements for functional safety (IEC 61508 SIL 2 capable) and machinery protection standards (API 670, ISO 10816).

Key Features

• Dual-Channel Monitoring: Simultaneously measures axial position and differential expansion with independent calibration and alarm logic per channel.
• Advanced Signal Conditioning: Digital filtering, automatic zero tracking, and temperature-compensated gain ensure stable output across wide ambient ranges (–40 °C to +85 °C operating).
• Configurable Alarms & Relays: Four programmable relays (two per channel) with time-delayed, latching, or non-latching modes; configurable via 3500 Rack Configuration Software (RCS) or front-panel interface.
• Robust Industrial Design: DIN-rail mountable, 3500-series compatible chassis; IP20-rated enclosure; CE, UKCA, and RoHS compliant.
• Seamless System Integration: Native support for 3500 rack backplane communication; optional Modbus RTU (RS-485) and EtherNet/IP modules for plant-wide data visibility.

Specifications

• Part Number: 139211-01
• Manufacturer: Bently Nevada (a Baker Hughes business)
• Type: Position Monitor Module (for Machinery Protection Systems)
• Warranty: 24 months limited warranty from date of shipment, covering defects in materials and workmanship under normal use and service conditions.

Contact us for bulk pricing and availability
