Product Overview

The Siemens 6AV6644-0AC01-2AX1 serves as a high-performance operator interface within the SIMATIC MP 377 product line. This 19-inch multi-panel facilitates advanced process visualization and control in complex industrial environments. By utilizing a high-resolution TFT display, the unit presents critical process data clearly, which allows operators to monitor and manipulate system parameters with high precision.

Technical Specifications

• Model Number: 6AV6644-0AC01-2AX1
• Manufacturer: Siemens
• Device Type: Multi-Panel HMI
• Display Size: 19-inch TFT Color Display
• Resolution: 1280 x 1024 Pixels
• Operating System: Windows CE 5.0
• Memory: 12 MB Configuration Memory
• Power Supply: 24V DC
• Power Consumption: 60 W
• Rated Current: 2.5 A
• Dimensions: 50.8 cm x 20.3 cm x 66.0 cm
• Weight: 7.7 kg
• Protection Class: IP65 (Front)

Functional Characteristics

Engineers design this panel to meet the rigorous demands of continuous industrial operations. The device utilizes a resistive touch screen interface, which ensures reliable input capture even in harsh factory conditions. Furthermore, the unit integrates seamlessly into existing automation architectures through standard industrial communication protocols. The system supports configuration via WinCC flexible software, which grants developers the flexibility to create customized HMI screens tailored to specific application requirements. Because the unit features an MTBF of 50,000 hours for backlighting, it provides long-term stability, which consequently reduces the necessity for frequent hardware maintenance.

Industrial Applications
