Description

The Schneider Electric BMXDDO3202K serves as a high-density digital interface for the Modicon X80 automation platform. This module features 32 solid-state output channels. It provides reliable control for 24V DC industrial actuators. Because it utilizes positive logic (source), it integrates easily with standard industrial control circuits. The hardware follows a compact, single-slot design. This allows engineers to maximize rack space in M340 or Quantum Ethernet I/O systems.

Advanced Output Performance and Protection

Each channel handles a nominal current of 0.1A. The total module capacity reaches 3.2A for simultaneous operations. Furthermore, the solid-state design ensures rapid switching speeds and long-term durability. The module maintains low leakage current below 0.1mA. It also limits voltage drop to less than 1.5V during active states. These characteristics prevent false triggering and energy loss. Robust insulation resistance exceeding 10MΩ protects the internal circuitry from electrical noise.

Rugged Design for Industrial Environments

The module operates reliably within a temperature range of 0°C to 60°C. Its IP20-rated housing protects against solid objects in cabinet installations. Moreover, the French-engineered construction meets global EN/IEC 61131-2 standards. This ensures high performance in manufacturing and process control. The module uses a high-density connector to simplify terminal wiring. Consequently, it reduces the physical footprint of the PLC assembly.

Technical Parameters and Specifications
