Description

The GE Fanuc IC693CPU351 serves as a high-tier processor within the Series 90-30 Programmable Logic Controller family. This module manages complex automation sequences by executing user-defined logic at high speeds. It utilizes an Intel 80386EX microprocessor to handle demanding computational tasks. Consequently, industrial facilities often deploy this CPU for large-scale data processing and sophisticated machine control. Its modular design allows for seamless integration into standard Series 90-30 baseplates.

Advanced Technical Specifications

This processor offers a significant increase in memory and I/O capacity compared to entry-level models. It supports a wide variety of digital and analog configurations.

• Processor Type: 80386EX running at 25 MHz
• User Memory: 240 Kilobytes
• Discrete I/O Capacity: 2048 Points
• Analog I/O Capacity: 32,640 Channels
• Power Requirement: 890 mA at 5V DC
• Serial Communication: 3 Integrated Ports (Supports SNP/SNP-X)
• Register Memory: 9,999 Words
• Internal Timers/Counters: Over 2,000 available

System Connectivity and Communication

The IC693CPU351 provides superior flexibility through its triple serial port architecture. These ports facilitate simultaneous connections to programming terminals, HMI panels, and other peripheral devices. The CPU supports various protocols to ensure smooth data exchange across the factory floor. Furthermore, it manages floating-point math functions to improve control precision. This capability makes it suitable for complex motion control and process optimization. The module also supports PCM and Ethernet interface modules for expanded networking.

Installation and Environmental Protection

Reliability remains a priority for the IC693CPU351 in rigorous industrial settings. Proper installation requires specific grounding techniques to mitigate electromagnetic interference. Users can utilize a dedicated green grounding wire or a specialized mounting bracket. These components prevent electrical noise from disrupting sensitive logic operations. The CPU features a compact footprint to save valuable space inside control cabinets. Additionally, the unit includes a battery-backed RAM system to preserve data during power interruptions. This ensures a faster recovery and minimizes production downtime.
