Description

The B&R X20CP1586 serves as a high-tier computational hub for the X20 automation platform. This module utilizes an Intel Atom dual-core processor running at 1.5 GHz. It manages complex control algorithms and high-speed data processing with ease. Furthermore, the unit features a fanless design to increase mechanical reliability. The processor includes 512MB of DDR2 RAM for efficient multitasking. Consequently, it handles demanding machine logic while maintaining low power consumption. This combination makes it a core component for modern industrial machinery.

Technical Specifications

• Brand Name: B&R (Bernecker + Rainer)
• Model Designation: X20CP1586
• CPU Architecture: Intel Atom Dual Core 1.5 GHz
• System Memory: 512MB DDR2 SDRAM
• Storage Type: Removable CompactFlash Slot
• Network Ports: Gigabit Ethernet, POWERLINK V1/V2
• Expansion Options: 3 Multi-purpose Interface Slots
• Operating Temperature: -25°C to +60°C
• Weight: 0.38 kg
• Dimensions: 15.1 x 10.5 x 8.4 cm

Connectivity and Expansion

The X20CP1586 offers extensive networking capabilities through integrated Gigabit Ethernet and USB interfaces. It supports POWERLINK real-time communication for deterministic motion control applications. Additionally, three internal slots allow for modular interface expansion. Technicians can add specific fieldbus protocols to meet diverse site requirements. The integrated I/O processor manages up to 128 X20 modules simultaneously. This synchronization occurs at nanosecond levels to ensure precise system timing. Therefore, the controller integrates perfectly into large-scale distributed architectures.

Industrial Reliability and Redundancy

B&R engineered this module to perform in challenging production environments. It resists significant vibration and operates across a broad temperature spectrum. Moreover, the hardware supports full CPU redundancy for high-availability applications. This feature prevents system downtime during critical manufacturing phases. The use of removable CompactFlash cards simplifies the backup and deployment process. These design choices reflect a focus on long-term serviceability and plant safety.

Field Applications

This controller excels in high-speed packaging lines and complex CNC systems. Its dual-core performance specifically benefits multi-axis motion control and robotics. Furthermore, the unit manages large data volumes for industrial IoT integration. Many facilities in the plastics and textile industries rely on its deterministic timing. Its Swedish-designed robustness ensures consistent output in continuous process sectors. By choosing the X20CP1586, operators achieve a future-proof foundation for their automation needs.
