Description

The Bently Nevada 330100-50-05 serves as the primary 330100 Proximitor Sensor utilized to execute non-contact displacement and vibration measurements across Bently Nevada 3300 Series Machinery Protection platforms. Consequently, this non-contacting sensor translates the physical gap variation between the probe tip and a rotating shaft into an analog radio frequency feedback loop.

Suffix Breakdown & Model Matrix

• 330100: Base part number for 3300 Series 5 mm and 8 mm Proximitor Sensor.
• -50: Total length option specifying a 5.0 meter (16.4 feet) combined electrical system length configuration.
• -05: Agency approval option specifying multiple global certifications, including ATEX, IECEx, and CSA for hazardous area intrinsic safety parameters.

Hardware Specifications

Transducer Interface & Mechanical Monitoring Characteristics

This Proximitor sensor drives a fixed radio frequency signal loop to main electrical boundaries, sustaining precise eddy-current probe scaling when reading movements on targets like AISI 4140 steel. The internal hardware executes steady-state demodulation to support immediate gap voltage validation (-10 VDC targets) over a standard 2.0 mm linear field. Furthermore, the specialized low-pass active filter design provides native cross-talk suppression against adjacent sensors grouped inside the same bearing block, shielding raw dynamic waveforms from high-frequency external emissions to precisely map rotor dynamics.

Frequently Asked Questions

Q: What measurement anomalies occur if this 5.0-meter Proximitor matches with a 9.0-meter probe and cable hardware matrix?

A: The circuit calibration relies on strict internal balance constants calibrated to a 5.0-meter total electrical path. Combining this device with a 9.0-meter hardware setup results in an impedance mismatch, which degrades the incremental scale factor and skews the baseline gap reading.

Q: How does operating input potential affect the linear measurement limits of the 330100-50-05 assembly?

A: The module demands a nominal voltage of -24 VDC. Supplying a lower power level, such as one more positive than -23.5 VDC, reduces internal signal headroom and restricts the effective linear range of the dynamic measurement.

Field Installation Guidelines

1. Secure the aluminum housing panel directly to an isolated bulkhead plate or position it within a clean, environmental-type junction enclosure.
2. Verify that the combined lengths of the proximity probe and extension cable measure exactly 5.0 meters before hooking up the RF coax input.
3. Terminate the raw power and signal output wires to the screw blocks, maintaining a separation barrier away from noisy high-voltage motor links.
4. Check that the common power supply terminal remains at least 500 VDC isolated from the machinery chassis ground to prevent electrical loop contamination.
