Bently Nevada 121M6466 Ranger Pro Wireless Sensor
Bently Nevada 121M6466 Ranger Pro Wireless Sensor. Brand New Original Stock available for Global Shipping.
Description
The Bently Nevada 121M6466, also cataloged as the 121M6466 Wireless Sensor, operates as a dedicated hardware component for triaxial vibration and temperature data acquisition within Ranger Pro machinery monitoring networks.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 121M6466 |
| Brand | Bently Nevada |
| Origin | USA |
| Weight | 230 g |
| Dimensions | Compact Stud-Mount Sensor Housing |
| Operating Temp | -40 deg C to +125 deg C |
| Power Consumption | Internal replaceable battery, up to 5 years operating life |
| Product Type | Wireless Vibration Sensors |
| Sensor Type | Triaxial wireless accelerometer with integrated temperature sensor |
| Frequency Range | 0.1 Hz to 20 kHz |
| Acceleration Range | +/-1 g to +/-20 g |
| Wireless Protocol | ISA100 |
| Wireless Range | Up to 150 meters (line of sight) |
| Mounting Options | Direct mount or tethered for high-temperature zones |
| Environmental Rating | IP67; CSA Class I, Division 1 certified |
| Software Integration | Fully compatible with System 1 software |
Transducer Signal Conditioning & Rotor Dynamics
The 121M6466 conditions dynamic triaxial acceleration signals across three orthogonal axes (X, Y, Z) alongside surface temperature readings for direct wireless routing to System 1 condition monitoring software. Internal signal processing circuits scale dynamic waveform, FFT spectra, and PeakDemod data while providing active cross-talk suppression between orthogonal measurement channels. Consequently, this multi-axis capability enables precise evaluation of rotor dynamics, structural resonance, bearing degradation, and shaft misalignment without requiring complex field wiring infrastructure.
Frequently Asked Questions
Q: How does the 121M6466 maintain signal integrity across three vibration measurement axes?
A: The sensor integrates multi-channel conditioning circuits with internal cross-talk suppression to isolate triaxial vibration inputs prior to wireless transmission over the ISA100 protocol.
Q: What data output formats does the 121M6466 supply to System 1?
A: The sensor generates timebase waveforms, FFT spectra, PeakDemod diagnostic signals, and direct casing temperature measurements.
Field Installation Guidelines
- Thread the 121M6466 directly onto a prepared mounting stud or magnetic base on the machine bearing housing, ensuring flush surface contact for vibration transfer.
- Ensure direct metal-to-metal contact between the metallic base and the machine casing to maintain accurate temperature conduction.
- Position the sensor to establish an unobstructed line-of-sight wireless path to the ISA100 gateway, remaining within the 150-meter range boundary.
- Verify that the IP67 housing seals remain fully seated following battery insertion to protect internal electronics against dust and moisture.
Additional information
| Weight | 0.23 kg |
|---|---|
| Dimensions | 51 × 43 × 93 mm |
