Description

The ABB 23TP22 1KGT013000R0001 serves as a high-precision power supply unit for advanced process systems. This module provides stabilized voltage to critical control circuits within distributed control system (DCS) architectures. It specifically integrates with Tmax XT circuit breaker series to enhance protection capabilities. The unit ensures that electronic components receive consistent power despite fluctuations in the primary supply. Its engineering focuses on long-term stability in heavy-duty manufacturing environments.

Core Specifications

• Brand Name: ABB
• Model Designation: 23TP22
• Part Number: 1KGT013000R0001
• Product Type: Power Supply Unit
• Manufacturing Origin: Sweden
• Physical Mass: 2.46 kg
• Outer Dimensions: 48 x 26.3 x 19.5 cm
• System Category: DCS / Advanced Process Control
• Tariff Code: 8537101190

Operational Performance

This power module incorporates advanced filtering technology to mitigate electrical noise and interference. Consequently, the unit maintains signal integrity for connected communication processors and I/O modules. The robust metal housing effectively dissipates heat during continuous high-load operations. Furthermore, the 23TP22 supports real-time diagnostic monitoring for proactive system maintenance. Its design withstands significant mechanical vibrations common in industrial plant floors.

Integration and Application

The 23TP22 excels in process control, power distribution, and automated manufacturing sectors. Technicians can easily install the unit using the dedicated extension mounting panel. This flexibility allows for rapid deployment within complex control cabinets. Because the module supports Ethernet routing services, it bridges power delivery with data connectivity. This dual functionality optimizes cabinet space and reduces overall wiring complexity.

Reliability Standards

ABB manufactured this unit to meet rigorous international safety and quality standards. Although discontinued in late 2018, it remains a vital component for legacy system support. The module provides essential circuit protection to prevent damage to downstream sensitive electronics. Therefore, it contributes significantly to maximizing system uptime and reducing unplanned operational halts.
