Bently Nevada 3300/05-23-00-00 3300 Series System Rack
Bently Nevada 3300/05-23-00-00 is an 8-slot standard mount system rack designed for 3300 series monitors. Brand New, Original Stock with Global Shipping.
Description
The Bently Nevada 3300/05-23-00-00 serves as the primary 3300/05 System Rack utilized to execute structural housing and backplane power distribution across Bently Nevada 3300 Series Machinery Protection platforms. Consequently, this chassis provides a unified physical infrastructure to connect individual monitoring cards, power modules, and key phasors.
Suffix Breakdown & Model Matrix
- 3300/05: Base part number for the 3300 System Rack mainframe.
- -23: Rack size option designating an 8-position configuration footprint (houses 1 Power Supply, 1 System Monitor, and up to 6 individual monitor modules).
- -00: Agency approval option specifying approval is not required.
- -00: Mounting option specifying standard structural panel mount configuration.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 3300/05-23-00-00 |
| Brand | Bently Nevada |
| Origin | United States |
| Weight | 4.82 kg |
| Dimensions | 355.6 mm x 265.9 mm x 349.3 mm |
| Operating Temp | -20 to +65 deg C |
| Power Consumption | Passive backplane layout (distribution bus only) |
| Slot Configuration | 8 total positions (Position 1: Power, Position 2: System Monitor, Positions 3-8: Channels) |
| Structural Material | Conductive injection-molded antistatic polymer |
| Backplane Wiring | Pre-routed integrated circuitry (eliminates manual discrete wiring loops) |
Transducer Interface & Mechanical Monitoring Characteristics
This modular chassis framework stabilizes backplane impedance pathways for low-level proximity inputs, thereby preserving precise eddy-current probe scaling for every active slot. The solid power rail layout maintains clean supply voltage delivery to guarantee stable gap voltage validation (-10 VDC targets) across dynamic measuring cards. Furthermore, the antistatic conductive polymer structure achieves continuous cross-talk suppression and isolates electrostatic discharge (ESD), protecting the raw sensor streams that track industrial rotor dynamics.
Frequently Asked Questions
Q: How are power supplies and system monitors systematically arranged in this 8-position rack?
A: The physical backplane enforces a strict slot configuration. Specifically, technicians must install the primary system power supply exclusively into the left-most slot (Position 1) and seat the main System Monitor immediately adjacent in Position 2.
Q: Can an installation technician hot-swap 3300 modules inside this backplane assembly while powered?
A: No, the 3300/05 chassis does not support live module insertion or removal. Technicians must completely isolate and disconnect the primary power feed before replacing any card to prevent high-voltage electrical arcing across backplane pins.
Field Installation Guidelines
- Cut out flat panel spaces matching the exact physical dimensions of the 8-position housing assembly before positioning the framework.
- Tighten all exterior panel fasteners evenly to prevent structural frame twisting from persistent heavy industrial machinery vibration.
- Fasten a heavy-gauge copper grounding strap directly from the chassis grounding lug to the main plant instrumentation ground bus.
- Keep the integrated front bezel pathways clear to ensure clear visibility of point-identification tags and paper loops.
