Description

Siemens 6SL3130-7TE21-6AA4 as a high-performance Active Line Module within SINAMICS S120 drive systems. This Booksize format unit converts three-phase AC input into a stable DC link voltage. The module supports regenerative feedback, allowing energy return to the supply during braking. Operators benefit from internal air cooling that simplifies cabinet design and reduces external fan requirements. DRIVE-CLiQ integration enables seamless communication with control units and motor modules automatically. The device delivers a rated power of 16 kW with a continuous current of 27 A. Input voltage ranges from 380 to 480 V AC to accommodate global industrial standards. Output voltage stabilizes between 510 and 720 V DC for consistent motor operation. Advanced current controllers ensure precise power management during dynamic load changes. Protection circuits monitor temperature and voltage to prevent damage under fault conditions.

Technical Specifications

Application and Integration

Facilities deploy this module in applications requiring four-quadrant operation and energy efficiency. The compact design fits easily into space-constrained control panels alongside other Booksize components. Technicians connect the unit directly to the DC bus for immediate power distribution to motor modules. Regenerative capabilities reduce overall energy consumption in high-cycle machinery like cranes or centrifuges. The integrated DRIVE-CLiQ interface simplifies wiring and accelerates commissioning processes significantly. Robust construction ensures reliable performance in harsh industrial environments with varying temperatures. Maintenance teams access diagnostic data through the Ethernet router connection for proactive troubleshooting. This active product supports both new machine builds and existing system upgrades globally.
