Description

The Schneider Electric ATV930C22N4 is a high-performance frequency inverter from the Altivar Process 900 series. This 22 kW (30 HP) drive excels in managing demanding motor control tasks for three-phase asynchronous and synchronous systems. It operates across a voltage range of 380V to 480V AC. The drive provides the necessary torque and precision for the most rigorous industrial processes.

Superior Control for Process Industry Excellence

This drive specializes in high-dynamic applications that require strict motor performance. It features advanced master/slave configurations to ensure synchronized operation across multiple drive units. Furthermore, the integrated braking unit allows for efficient deceleration of high-inertia loads. This capability makes the drive an essential component for complex mechanical systems.

Maintenance teams benefit from the built-in web server and extensive data logging tools. These digital features allow for real-time diagnostics and predictive maintenance planning. Consequently, facilities can reduce unplanned downtime and optimize their total cost of ownership. The unit also maintains network resilience during communication drops to ensure continuous operation.

Targeted Application Areas

The Altivar ATV930C22N4 thrives in heavy-duty sectors such as oil and gas extraction. It provides reliable control for mining crushers and heavy-duty conveyor systems. Additionally, the drive supports large-scale water treatment facilities and metal processing plants. Its rugged design withstands harsh electrical environments while delivering superior energy efficiency. This drive represents a future-ready solution for smart factories seeking maximum process visibility.

Connectivity and Technical Specifications

• Power Rating: 22 kW / 30 HP
• Supply Voltage: 380…480 V AC (Three-Phase)
• Overload Capacity: 120% for 60 seconds (Normal Duty)
• Degree of Protection: IP00 (Standard version)
• Communication: EtherNet/IP, Modbus TCP, and Modbus Serial
• Functional Safety: STO (Safe Torque Off) SIL 3
• Weight: 28.5 kg (Note: Corrected industrial weight for 22kW ATV930)
• Dimensions: 226 x 613 x 271 mm (Standard frame size)
