The Allen-Bradley MOX720-P4668E (80026-518-01) is a specialized industrial switching power supply that converts a 56VDC input into three regulated DC outputs. It provides high-efficiency power distribution for complex PLC systems and OEM automation machinery.

Specialized Triple-Output DC Power Architecture

The Allen-Bradley MOX720-P4668E, identified by part number 80026-518-01, functions as a high-performance switching regulator for sophisticated industrial applications. This module accepts a nominal 56VDC input and precisely distributes power across three distinct rails: 5V, 15V, and 24V DC. Because it delivers 5A, 2A, and 1A respectively on these outputs, the module provides a versatile energy solution for mixed-voltage control architectures. Consequently, engineers can power logic circuits, analog sensors, and relay actuators from a single, centralized component, which effectively reduces the complexity of the internal cabinet wiring.

Advanced Thermal Management and Efficiency

System longevity depends heavily on heat mitigation, and the MOX720-P4668E excels in this area through synchronous rectification technology. This design choice significantly optimizes power conversion efficiency while simultaneously reducing the thermal footprint of the device. Because the module generates less waste heat, it permits higher packing densities within control enclosures without compromising the reliability of adjacent PLC components. Furthermore, this increased efficiency translates directly into lower operational energy costs and diminished requirements for active cooling systems in high-demand environments.

Integrated Diagnostics and Fault Protection

Safety and uptime remain critical in automated manufacturing, prompting the inclusion of comprehensive protective features in the 80026-518-01 power module. The unit incorporates a DC-OK relay contact and prominent status LEDs, allowing maintenance teams to verify system health at a glance. Additionally, built-in fuses and robust current-limiting circuitry protect the supply against fluctuating load conditions and potential short circuits. These safeguards prove particularly beneficial when the module powers heavy-duty equipment, such as DC motors, where high inrush currents are common during the startup phase.

Global Compatibility and Deployment Versatility

The compact form factor of the MOX720-P4668E facilitates its integration into a wide variety of factory automation and process control systems. Beyond its space-saving design, the module features low electromagnetic interference (EMI) profiles, ensuring it does not disrupt sensitive communication lines or Ethernet routers within the DCS network. With its broad range of international approvals and proven performance in USA-origin manufacturing, this power supply represents a dependable choice for global OEM equipment and critical infrastructure upgrades.

Key Technical Characteristics

• Triple-Rail DC Output: Supplies regulated 5V, 15V, and 24V DC to support diverse hardware requirements.
• Synchronous Rectification: Enhances conversion efficiency and reduces internal heat generation.
• Real-Time Diagnostics: Features status-indicating LEDs and a DC-OK relay for remote monitoring.
• High Inrush Tolerance: Specifically engineered to manage the startup demands of DC motors and heavy inductive loads.
• Robust Protection Suite: Includes integrated primary/secondary fuses and overvoltage suppression.
• Minimal EMI Profile: Optimized for low noise to protect the integrity of nearby signal and data cables.
