Description

Brief Product Description

The GE Fanuc IC200CHS022 is a compact, box-style terminal carrier designed to provide a secure wiring interface for VersaMax I/O modules.¹ It functions as a foundational base, allowing for seamless I/O module installation and field wiring connectivity in industrial PLC environments.²

​Product Description

Integrated Field Wiring Interface

The GE Fanuc IC200CHS022 functions as a high-density terminal base within the Emerson VersaMax ecosystem.³ This carrier serves the essential role of bridging field-side input and output devices with the logic processing modules. By featuring 36 individual IEC box-style screw terminals, the unit accommodates a wide array of wiring configurations.⁴ The layout utilizes two distinct rows, labeled A1 through A18 and B1 through B18, which simplifies the identification and organization of complex control circuits. This structured approach significantly reduces the likelihood of wiring errors during the initial installation phase.

Mechanical Design and Thermal Management

Engineered for space-constrained control cabinets, the IC200CHS022 utilizes a compact footprint that supports both standard 35mm DIN rail and direct panel mounting.⁵ To maintain long-term reliability, the module’s installation guidelines specify a horizontal clearance of 1 inch and vertical clearance of 2 inches. This spacing facilitates natural convection, ensuring that heat dissipates effectively from the carrier and the attached I/O module. Furthermore, a built-in hinged card holder provides a dual benefit: it firmly locks the I/O module in place while simultaneously shielding the terminal connections from accidental contact or debris.⁶

Simplified Maintenance and Operational Durability

The modular architecture of the IC200CHS022 provides a significant advantage for facility maintenance. Because the wiring terminates at the carrier rather than the I/O module itself, technical personnel can replace or upgrade functional modules without disturbing the existing field cables. This “plug-and-play” capability minimizes system downtime and protects the integrity of the screw connections over time. Capable of handling up to 264 VAC and supporting 2A per terminal, the carrier withstands the electrical stresses typical of heavy industrial applications. The robust design ensures stable operation across a temperature spectrum of 0°C to 60°C.⁷

Technical Specification Overview
