Description

Brief Product Description

The Allen-Bradley MIM105-Q6949 (80026-096-01) is a high-efficiency DC-DC switching power supply designed to convert a 48VDC input into a regulated 24VDC output. This compact module provides stable, low-noise power for sensitive PLC components and industrial automation sensors.

High-Precision DC-DC Power Conversion

The Allen-Bradley MIM105-Q6949, also cataloged as 80026-096-01, functions as a critical power regulation interface for sophisticated industrial networks. This switching mode power supply accepts a 48VDC input at a maximum of 1.5A and transforms it into a highly stable 24VDC output rated at 2A. By maintaining precise voltage levels, the module ensures that connected electronic devices receive consistent energy, which is vital for preventing data corruption in control logic and maintaining the accuracy of analog instrumentation. Consequently, the MIM105-Q6949 acts as a dependable buffer against input voltage swings commonly found in heavy industrial power grids.

Compact Engineering for Space-Constrained Environments

Modern control cabinets often face severe spatial limitations, which the MIM105-Q6949 addresses through its slim and efficient form factor. Measuring only 20.7 x 5 x 2.5 cm, this Absopulse-engineered switching supply integrates easily into crowded DIN rail layouts or specialized OEM enclosures. Furthermore, the unit utilizes advanced heat dissipation techniques to maintain high performance without the need for bulky external cooling fans. Because it minimizes the thermal load within the cabinet, the power supply helps extend the operational lifespan of surrounding automation hardware and reduces the frequency of maintenance interventions.

Rugged Durability and System Compatibility

Engineers prioritize the 80026-096-01 for its proven resilience in harsh manufacturing environments, including robotics and high-speed production lines. The module features a robust internal construction that protects sensitive switching circuitry from the mechanical vibrations and electromagnetic interference (EMI) typical of industrial sites. Moreover, this power supply demonstrates seamless compatibility with the broader Allen-Bradley PLC ecosystem, facilitating straightforward upgrades and replacements. Its reliable execution of power delivery supports continuous uptime, making it a trusted cornerstone for mission-critical process control and smart manufacturing initiatives.

Key Technical Characteristics

• Efficient Voltage Stepping: Converts 48VDC source power to a regulated 24VDC output for standard automation hardware.
• Optimized Current Output: Delivers a steady 2A output current to drive multiple sensors or small actuator banks.
• Slim Profile Design: Ultra-compact dimensions allow for high-density mounting in confined electrical panels.
• Advanced EMI Suppression: Features internal filtering to prevent electrical noise from disrupting nearby communication and Ethernet routers.
• Industrial Grade Longevity: Built with high-quality components to ensure a long service life in continuous 24/7 operations.
• Wide Input Tolerance: Manages input current up to 1.5A while maintaining a ripple-free DC output.
