The ABB SNAT632PAC (61049428) is a high-performance pulse amplifier board engineered to distribute TC link information from APC controllers to multiple inverters via fiber optic interfaces. It ensures precise signal synchronization and long-distance transmission integrity within industrial drive architectures.

​Product Description

The SNAT632PAC (Part Number: 61049428) functions as a vital communication bridge within ABB industrial drive systems. This PAC Pulse Amplifier Board primarily manages the distribution of TC link data, allowing a single APC controller to synchronize and command up to four independent inverters. By utilizing optical fiber technology, the module eliminates electromagnetic interference, which often plagues traditional copper-based signaling in high-power industrial environments. This isolation ensures that pulse commands remain crisp and synchronized across all connected drive components.

Optical Transmission and Network Versatility

Engineers designed the 61049428 with flexibility in mind, incorporating plastic fiber optic connectors as the standard interface. However, the system maintains broader compatibility with glass fiber networks through the use of external distributors. The board supports reliable transmission over various distances depending on the media utilized; standard cables facilitate links up to 15 meters, while extra low attenuation fibers extend the reach to 25 meters. This versatility allows the SNAT632PAC to adapt to diverse cabinet layouts and large-scale manufacturing floor configurations without sacrificing signal speed or accuracy.

Robust Electrical and Physical Design

Operating on a standard 19–30 VDC power supply, the SNAT632PAC (Part Number: 61049428) demonstrates high energy efficiency with a power consumption of only 1.9 VA. ABB houses the internal electronics in a ruggedized metal enclosure, which provides a physical shield against mechanical impact and environmental contaminants. Measuring 155 × 40 × 72 mm, the compact form factor allows for high-density mounting in control cabinets. This robust construction, combined with Sweden’s manufacturing standards, guarantees long-term operational stability and reduces maintenance overhead in critical automation processes.
