The Allen-Bradley 2094-BC01-M01-S is a high-performance Integrated Axis Module (IAM) for the Kinetix 6000 series, combining power conversion and motion control into a single unit. It provides 6kW of converter power and 9A of continuous output to drive precision servo motors while ensuring operational safety through integrated hardware.

High-Performance Power Conversion and Control

The 2094-BC01-M01-S functions as the primary power anchor for multi-axis Kinetix 6000 systems. By consolidating the converter and inverter sections, this module efficiently manages power distribution for the entire drive rail. It operates on a 460V AC three-phase input and provides a steady 3.9kW output wattage, supporting demanding motion profiles. Transitioning to this integrated architecture allows engineers to reduce panel space and simplify wiring. Furthermore, the module handles peak torque demands of up to 250%, enabling high-acceleration cycles without requiring oversized power supplies.

Advanced Motion and Feedback Support

Designed for versatility, the 2094-BC01-M01-S supports an extensive range of Allen-Bradley rotary and linear motors, including the MP-Series, TL-Series, and LDAT linear actuators. It utilizes a SERCOS interface for high-speed, noise-immune communication over fiber optic cables. This digital interface facilitates precise synchronization between axes in both linear and ring topologies. Because the module supports multiple feedback types, it integrates effortlessly into complex automation environments that require high-resolution position data and rapid response times.

Integrated Safety and Compliance

Safety remains a foundational priority for the 2094-BC01-M01-S, which features a factory-installed Safe Torque Off (STO) function. This safety circuit meets ISO 13849-1 PLe and SIL3 standards, ensuring that the drive cannot generate torque after a safety event occurs. By preventing unexpected restarts, the module protects both personnel and equipment during maintenance or emergency stops. For facilities needing EN954-1 Category 3 compliance, the module’s safety headers allow for straightforward integration with external safety relays, providing a robust and certified machinery protection solution.
