Description

The Schneider Electric ATV212HU75N4 provides dedicated frequency control for HVAC applications. This 7.5 kW (10 hp) drive belongs to the Altivar 212 series. It specifically optimizes the performance of pumps, fans, and compressors. Furthermore, the unit operates on a three-phase supply between 380V and 480V AC. The design focuses on reducing energy consumption in commercial buildings. Because it eliminates throttling valves and dampers, it significantly lowers operational costs. This drive integrates seamlessly into ventilation and climate control architectures.

Technical Specifications

• Brand: Schneider Electric
• Model Number: ATV212HU75N4
• Product Series: Altivar 212
• Motor Power: 7.5 kW / 10 hp
• Input Voltage: 380V to 480V AC (Three-Phase)
• Line Current: 14.7A at 380V / 11.7A at 480V
• Continuous Output Current: 16A at 380V / 480V
• Protection Rating: IP21 (UL Type 1)
• Integrated Communication: Modbus, METASYS N2, APOGEE FLN, BACnet
• EMC Filter: Integrated Class C2 filter
• Weight: 3.35 kg
• Origin: France

Advanced Monitoring and Diagnostics

This Altivar 212 module includes an intuitive interface for real-time system oversight. Users can access the Monitoring mode by pressing the MODE key. Consequently, the display provides instant visibility into 30 different operational metrics. These data points include output frequency, motor speed, and current draw. This transparency simplifies troubleshooting and routine performance audits. Additionally, the parameter reset function allows for rapid motor frequency synchronization. Technicians can toggle between 50 Hz and 60 Hz configurations effortlessly. These features ensure the drive remains adaptable to global electrical standards.

Infrastructure Compatibility and Reliability
