Schneider Altivar 212 75kW VFD ATV212HD75N4 for HVAC and Pump Control
The Schneider ATV212HD75N4 is a 75kW (100HP) variable frequency drive designed for HVAC fans and pumps. It features integrated EMC filters, multi-protocol communication (BACnet/Modbus), and offers up to 70% energy savings.
Description
Brief Product Description
The Schneider Electric ATV212HD75N4 is a high-performance 75kW (100HP) variable speed drive optimized for HVAC applications in commercial buildings.2 It delivers superior motor control and energy efficiency for fans and pumps while integrating seamlessly into building management systems.
Product Description
Advanced Motor Control for HVAC Infrastructure
The Schneider Electric ATV212HD75N4 belongs to the renowned Altivar 212 series, specifically engineered to manage three-phase asynchronous motors in tertiary sector fluid applications. This 75kW drive operates within a voltage range of 380V to 480V AC and provides precise regulation for heating, ventilation, and air conditioning systems.3 By utilizing advanced law-of-motor control, the unit optimizes torque and speed, which significantly reduces mechanical stress on pump and fan assemblies.
Superior Energy Optimization and Harmonic Mitigation
Industrial facilities often face challenges with energy waste and electrical noise. The ATV212HD75N4 addresses these by achieving up to 70% energy savings compared to traditional fixed-speed starters.4 Furthermore, its unique design utilizes “Reduced-Capacitance” technology. This innovation mitigates current harmonics and minimizes cable temperature rise without the need for additional line chokes or DC bus reactors.5 Consequently, users benefit from a reduced footprint and lower installation costs while maintaining high power quality.
Seamless Building Automation Integration
System connectivity defines the modern HVAC environment. Schneider Electric equips the ATV212HD75N4 with an extensive array of embedded communication protocols, including Modbus, BACnet, METASYS N2, and APOGEE FLN P1.6 These interfaces allow the drive to communicate directly with Building Management Systems (BMS), providing real-time diagnostics and energy usage data. Additionally, the integrated EMC filter ensures the drive complies with electromagnetic compatibility standards, preventing interference with sensitive building electronics.7
Technical Specifications
| Feature | Details |
| Manufacturer | Schneider Electric |
| Model Number | ATV212HD75N4 |
| Product Range | Altivar 212 |
| Motor Power (kW) | 75 kW |
| Motor Power (HP) | 100 hp |
| Supply Voltage | 380…480 V AC (3-Phase) |
| Line Current | 141.8 A at 380 V |
| Protection Rating | IP21 |
| Network Frequency | 50/60 Hz |
| Communication | Modbus, BACnet, METASYS N2, APOGEE FLN |
| Dimensions | 630mm (H) x 320mm (W) x 290mm (D) |
| Net Weight | 55.4 kg (Note: Corrected from 1.9kg) |
Additional information
| Weight | 1.9 kg |
|---|---|
| Country of Origin | France |
| Dimension | 27.9 x 21.6 x 6.3 cm |
