Description

The Bently Nevada 125736-01 serves as the dedicated Internal Termination Development (ITD) I/O module for the 3500/92 Communication Gateway. This component facilitates high-speed data transfer between the 3500 Monitoring System and external control architectures. It acts as a bridge for critical machinery protection data. Engineers use this module to export static and dynamic variables to Distributed Control Systems (DCS) and Programmable Logic Controllers (PLC).

Hardware Interface and Connectivity

This module supports industrial protocols including Modbus RTU via RS232, RS422, and RS485 serial interfaces. The hardware design prioritizes signal integrity in high-interference environments. Users can configure the communication ports for various baud rates to match host system requirements. The unit slides into the rear of the 3500 rack. It connects directly to the 3500/92 Gateway processor through the backplane.

Industrial Applications and Reliability

Operators in oil and gas, power generation, and chemical processing rely on this module for Turbine Supervisory Instrumentation (TSI). The 125736-01 withstands the rigorous electrical noise found in industrial plants. Its robust construction ensures continuous operation during critical machinery monitoring phases. The module supports predictive maintenance by providing real-time access to vibration and position data.

Technical Specifications

• Manufacturer: Bently Nevada (Baker Hughes)
• System Series: 3500 Machinery Protection System
• Part Number: 125736-01
• Module Type: Communication Gateway I/O
• Protocols Supported: Modbus RTU (Serial)
• Physical Interfaces: RS232 / RS422 / RS485
• Weight: 0.42 kg
• Dimensions: 2.4 cm x 11.1 cm x 24.1 cm
• Mounting: Rear of 3500 Rack
