The Schneider Electric ATV610C16N4 is a high-capacity variable speed drive from the Easy Altivar 610 series, designed to optimize the performance of 160kW asynchronous motors. It provides reliable motor control for industrial pump, fan, and compressor applications within water and oil sectors.

Product Description

High-Efficiency Motor Control for Process Industry

The Schneider ATV610C16N4 serves as a specialized frequency converter engineered for the rigorous demands of industrial process management. This variable speed drive (VFD) efficiently regulates three-phase asynchronous and synchronous motors, supporting power ratings up to 160 kW (215 HP). By utilizing advanced motor control profiles for both constant and variable torque, the unit enhances energy efficiency in fluid management and material handling systems. Furthermore, the drive features factory-preset parameters that allow for immediate plug-and-play commissioning, significantly reducing the engineering time required for system integration.

Robust Hardware and Thermal Management

Designed for cabinet mounting, the ATV610C16N4 excels in harsh industrial climates through its forced convection cooling system. This architecture ensures optimal thermal dissipation, allowing the drive to maintain a continuous output current of 302 A under normal duty conditions. To ensure electromagnetic compatibility, the unit incorporates an integrated EMC filter that adheres to IEC 61800-3 category C3 standards. Consequently, the drive provides clean performance with minimal electrical interference. While the unit maintains an IP20 protection rating, its durable internal components are specifically treated to resist the corrosive atmospheres often found in oil, gas, and wastewater treatment facilities.

Versatile System Connectivity and Expansion

The ATV610C16N4 Schneider drive offers comprehensive integration possibilities for modern PLC and DCS architectures. While the standard hardware includes a Modbus serial port, an additional expansion slot supports various industrial protocols such as Profibus DP V1. Operators can utilize up to 16 preset speeds and an adjustable switching frequency range of 1 to 8 kHz to fine-tune process control. Moreover, the unit facilitates seamless scaling through optional I/O extension modules, allowing the drive to adapt as plant requirements evolve. This combination of communicative flexibility and precise speed regulation ensures the ATV610C16N4 remains a primary choice for global building and process management.
