The Bently Nevada 330101-00-26-10-02-05 is a high-precision, industrial-grade proximity probe engineered for continuous, non-contact vibration and position monitoring of rotating machinery. Manufactured by Baker Hughes (formerly Bently Nevada), a globally recognized leader in condition monitoring and predictive maintenance solutions, this probe is part of the trusted 3300 XL 8 mm sensor family—designed to deliver exceptional linearity, thermal stability, and electromagnetic interference (EMI) immunity in demanding process environments. The probe operates on the eddy-current principle, generating a high-frequency magnetic field that interacts with conductive target surfaces (typically ferromagnetic shafts or thrust collars) to produce a linear, analog voltage output proportional to gap distance. Its robust construction features a stainless steel housing, integral 5-meter low-noise coaxial cable with integral connector, and hermetically sealed electronics optimized for long-term reliability under extreme mechanical stress, temperature fluctuations (-30 °C to +120 °C operating range), and exposure to oil, steam, and corrosive atmospheres. This unit is supplied in New Surplus Condition, meaning it is unused, factory-fresh, and sourced directly from authorized Baker Hughes distribution channels or certified inventory partners. Each probe includes full traceability documentation, complies with ISO 9001:2015 manufacturing standards, and carries a comprehensive 24-month limited warranty covering material defects and workmanship. With precise dimensional consistency and calibrated sensitivity of 7.87 V/mm (200 mV/mil), the 330101-00-26-10-02-05 ensures seamless integration into existing 3300/3500 series monitoring systems without recalibration. Measuring 12.7 mm (0.5 in) in diameter and 114.3 mm (4.5 in) in overall length—including the integrated cable strain relief—the probe weighs only 227 g (8.0 oz), enabling flexible mounting on space-constrained bearing housings. Manufactured in the United States, it meets RoHS Directive 2011/65/EU compliance and adheres to IEC 61000-4 electromagnetic compatibility standards.

Detailed Specifications

Key Features

• Factory-Calibrated Precision: Each probe undergoes rigorous individual calibration at the Baker Hughes manufacturing facility, ensuring ±0.5% linearity across the full 2 mm range and documented NIST-traceable calibration certificates.
• Enhanced Thermal Stability: Advanced coil winding and compensation circuitry minimize thermal drift to less than 0.5% FS/°C—critical for turbine and compressor applications experiencing wide ambient swings.
• Integrated 5-Meter Cable: Eliminates field splicing; features low-capacitance, double-shielded coaxial construction with integral 3300-series compatible connector (M12 x 1.0 metric thread) and molded strain relief.
• Robust Mechanical Design: Hermetically sealed ceramic insulator, corrosion-resistant 316 SS housing, and shock-rated construction (50 g peak, 11 ms half-sine per MIL-STD-810G).
• EMI/RFI Immunity: Engineered with multi-stage filtering and grounded shield architecture to maintain signal integrity in high-noise environments near VFDs, switchgear, and arc furnaces.
• Plug-and-Play System Integration: Fully compatible with Bently Nevada 3300, 3500, and System 1 platforms; supports automatic sensor recognition and configuration via Asset Manager software.
• Extended Service Life: Rated for >100,000 hours MTBF under continuous operation; validated through accelerated life testing per IEEE 1012.
• Global Regulatory Compliance: Certified to ATEX II 2G Ex db IIC T4 Gb, IECEx Ex db IIC T4 Gb, and UL/cUL Class 1, Div 1, Groups B, C, D for hazardous area deployment.

Applications

• Rotating Equipment Monitoring: Shaft vibration, axial position, and differential expansion measurement on steam/gas turbines, centrifugal compressors, and large electric motors (500+ HP).
• Thrust Bearing Protection: Real-time detection of axial shaft movement to prevent catastrophic thrust collar contact in critical turbomachinery trains.
• Power Generation: Continuous monitoring of generator rotor position, turbine blade tip clearance, and governor actuator feedback in fossil, nuclear, and combined-cycle plants.
• Oil & Gas Infrastructure: Downhole pump monitoring, pipeline compressor stations, LNG train drivers, and offshore platform gas turbines operating under high humidity and salt spray conditions.
• Chemical & Refining Processes: Monitoring of high-speed centrifuges, reactor agitators, and FCC compressor sets exposed to hydrocarbons, H₂S, and caustic vapors.
• Predictive Maintenance Programs: Foundation sensor for AI-driven analytics platforms (e.g., Baker Hughes Digital Twin, GE Predix) enabling early fault detection of imbalance, misalignment, bearing wear, and rub events.
• Condition-Based Overhaul Scheduling: Provides quantitative displacement data to optimize maintenance windows, reduce unplanned downtime, and extend equipment service intervals by up to 35%.
• Regulatory Compliance Support: Delivers auditable, high-fidelity data required for ISO 10816-3, API RP 670 (4th Ed.), and ANSI/HI 9.6.4 vibration severity standards reporting.
